Land Scraper

Series

Hydraulic Forced Ejection

Land Scraper Models Quick Guide

Model	Straight Hitch	Heaped Capacity
M650	–	6.51 cu. yd. (4.98 cu. m)
M1000		10.12 cu. yd. (7.74 cu. m)
M1350		13.38 cu. yd. (10.21 cu. m)
M1700		16.93 cu. yd. (12.94 cu. m)
M2050		20.37 cu. yd. (15.55 cu. m)

Every Inch, Every Pound, Every Feature

Wider, Cleaner Cuts

Cutting widths up to 102 inches (259 cm) allow for maximum surface coverage in fewer passes.

Precision Ground Control

Adjustable cutting depths from 0 to 11 inches (28 cm) for fine-tuned grading performance.

High-Capacity Loads

Handle more material per trip with heaped capacities ranging from 6.5 to over 20 cubic yards.

Effortless Material Spread

Spreading depth of up to 14 inches (35.6 cm) ensures smooth distribution on
every pass.

More Features

Power-Ready Performance

Engineered for tractors with drawbar horsepower from 130 to over 425 HP.

Reliable Push-Off Design

Guarded hydraulic push-off cylinders provide smooth and consistent ejection in all conditions.

Heavy-Duty Build

Weighing up to 14,000 lbs (6,364 kg), each model is built for tough, all-season durability.

Steady & Secure

Ball-type steering and twin lift/gate cylinders give you confident control in every direction.

Built for Laser Precision

All models are GPS and laser-control ready for advanced grading and leveling systems.

*SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

Do It All,

Do It Right

Land Leveling: Smooth out uneven terrain for improved drainage, planting, or construction prep.
Road & Trail Maintenance: Grade and reshape gravel roads, farm trails, and access lanes.
Field Preparation: Remove high spots and fill low areas to improve crop performance and equipment efficiency.
Ditch Cleaning & Formation: Shape or clean drainage ditches to manage water runoff.
Topsoil Spreading: Evenly distribute soil, gravel, or other materials over a surface.

Snow Removal: Push or spread snow in yards, fields, or access roads.
Manure Management: Distribute and level manure piles or organic matter across a field.
Land Reclamation: Restore overused, compacted, or eroded areas to productive condition.
Driveway Building & Maintenance: Create or re-grade durable, smooth driveways.

Model Specifications

FEATURE	M650	M1000	M1350	M1700	M2050 SH	M2050 DOLLY
Heaped Capacity (cu. yd / cu. m)	6.51 / 4.98	10.12 / 7.74	13.38 / 10.21	16.93 / 12.94	20.37 / 15.55	20.37 / 15.55
Struck Capacity (cu. yd / cu. m)	4.41 / 3.37	6.63 / 5.07	10.60 / 8.10	10.60 / 8.10	15.79 / 12.05	15.79 / 12.05
Weight (lbs / kg)	5500 / 2500	8000 / 3636	9000 / 4090	12200 / 5545	14000 / 6364	13400 / 6091
Drawbar HP (min)	100	130	200	200	200	200
Drawbar HP (max)	150	225	425	425++	425++	425++
Cutting Width (in / cm)	80 / 203	85 / 216	85 / 216	102 / 259	102 / 259	102 / 259
Cutting Depth (in / cm)	0–8 / 20	0–8 / 20	0–8 / 20	0–11 / 28	0–11 / 28	0–11 / 28
Spreading Depth (in / cm)	0–12 / 31	0–14 / 35.6	0–14 / 35.6	0–14 / 35.6	0–14 / 35.6	0–14 / 35.6
Overall Height (in / cm)	58 / 147	65 / 165	80 / 203	80 / 203	80 / 203	80 / 203
Overall Length (in / cm)	252 / 640	275 / 698	299 / 840	331 / 840	349 / 840	349 / 840
Overall Width (in / cm)	92 / 234	100 / 254	100 / 254	N/A	116 / 294	116 / 294
Clearance (in / cm)	11 / 28	11 / 28	11 / 28	10.5 / 26.7	10.5 / 26.7	10.5 / 26.7
Frost Blade (in)	5/8 x 8 x 48	3/4 x 10 x 54	3/4 x 10 x 54	3/4 x 10 x 54	3/4 x 10 x 54	3/4 x 10 x 54
Push Off Cylinder Diameter (in / cm)	3 / 7.6	4 / 10.2	4.5 / 10.5	3 / 7.6	3.5 / 9	3.5 / 9
Twin Lift Cylinders Diameter (in / cm)	3 / 7.6	3.5 / 8.9	4 / 10.1	4 / 10.1	4 / 10.1	4 / 10.1
Twin Gate Cylinders Diameter (in / cm)	2.5 / 6.3	3 / 7.6	3 / 7.6	3 / 7.6	3 / 7.6	3 / 7.6
Steering Control	N/A	3.5 / 8.9	4.875 / 12.4	4.875 / 12.4	N/A	4.875 / 12.4
Standard Front Tires	550/45 R22.5	550/45 R22.5	550/45 R22.5	600/50 R22.5	600/50 R22.5	600/50 R22.5
Standard Rear Tires	550/45 R22.5	550/45 R22.5	550/45 R22.5	600/50 R22.5	600/50 R22.5	600/50 R22.5
